F5.4-F45 High Resolution Lens 116mm Focal Length Hawk Series V58 Mount

Brand Name : OPT

Model Number : OPT-VHK116/5.4-0.67X

Place of Origin : China

MOQ : 1 piece

Price : Negotiable

Payment Terms : T/T

Supply Ability : Negotiable

Delivery Time : 7 work days at the soonest

Packaging Details : Craft Box

Focal Length : 116mm

Working Distance(mm) : 219.58 | 212.58 | 204.38

Image Circle(mm) : 63mm

Weight : 0.68kg

Magnification x : 0.64X | 0.67X | 0.7X

Distortion(%) : 0.023% | 0.018% | 0.058%

Flange Focal Distance(mm) : 168 | 171 | 174.8

Object To Image Distance(mm) : 454.6 | 450.6 | 446.2

Contact Now

F5.4-F45 Line Scan Lenses 63mm Image Circle 116mm Focal Length Hawk Series V58 Mount OPT-VHK116/5.4-0.67X

Product Features

◆ High relative illuminance across the entire image and low vignetting
Relative distortion is below 0.018%
◆ Broad spectrum range is from 400 to 900nm and achromatic design.
◆ It is able to match 63mm image circle and under of line and area scan camera.

◆ High resolution optical design, compatible to line scan camera with 7.0μm pixel

◆ Line scan lenses aperture F/#: F5.4-F45

◆ Distortion(%) of lenses is 0.023% | 0.018% | 0.058%.

◆ Working distance(mm) : 219.58 | 212.58 | 204.38.

◆ Object to image distance(mm): 454.6 | 450.6 | 446.2.

◆ Focal length of line scan lenses of hawk series OPT-VHK116/5.4-0.67X is 116mm.

◆ Minimum distortion is 0.005% and total distortion is less than 0.1% and distortion at primary magnification.

◆ Magnification: 0.64X | 0.67X | 0.7X.

◆ Flange focal distance(mm) of OPT-VHK116/5.4-0.67X lens is 168 | 171 | 174.8.

Model Explanation

OPT-VHK116/5.4-0.67X

OPT: Brand name

V: V-Mount

HK: Hawk series line scan lenses

116: Focal length 116mm

5.4: F#: 5.4

0.67X: 0.67X primary magnification

Specifications

Product Name	OPT Hawk Series Line Scan Lenses
Model	OPT-VHK116/5.4-0.67X
Focal Length	116mm
Working Distance(mm)	219.58 \| 212.58 \| 204.38
Aperture F/#	F5.4-F45
Image Circle(mm)	63mm
Magnification x	0.64X \| 0.67X \| 0.7X
Distortion(%)	0.023% \| 0.018% \| 0.058%
Flange Focal Distance(mm)	168 \| 171 \| 174.8
Object To Image Distance(mm)	454.6 \| 450.6 \| 446.2
Camera Interface	V58
Weight(Kg)	0.68kg

Resolution Comparison

F5.4-F45 High Resolution Lens 116mm Focal Length Hawk Series V58 Mount

Image taken via OPT-VHK 120/5.8-1.0X Image taken via other lens

Application Examples: Capacitor surface inspection

Dimensions (mm)

OPT-VHK116/5.4-0.67X
